Charger Plus 2 GSM – Panel Socket / GSM Module
- Power
- 3,7 - 22 kW
- Phase
- Three-phase
- Max. Current
- 6 - 10 - 16 - 32A
- Output
- With panel socket
1 / 4
AC Wallbox EV Chargers
Charger Plus 2 GSM – 5 m Cable / GSM Module
Product Code
Charger Plus 2 GSM – 5 m Cable / GSM Module (BEV-2011-1005) is a wall-mounted AC charging station designed for permanent installation in residential, shared and workplace car parks. Key specifications: Power: 3,7 - 22 kW; Phase: Three-phase; Max. current: 6 - 10 - 16 - 32A; Output: 5 m Cable. Highlights: IP65 Protection, RFID Card Reader, Mobile App, LCD Display, WiFi. It can be specified for anything from a single home to multi-user residential, office and fleet car parks; our technical team supports site surveys and model selection. Add the product to your quote list to get volume and project pricing direct from the manufacturer.
- Power
- 3,7 - 22 kW
- Phase
- Three-phase
- Max. Current
- 6 - 10 - 16 - 32A
- Frequency
- 50/60 Hz
- Output
- with 5 m cable
- Connector
- Type 2 (IEC 62196-2)
Technical Specifications
| Power | 3,7 - 22 kW |
|---|---|
| Phase | Three-phase |
| Max. Current | 6 - 10 - 16 - 32A |
| Frequency | 50/60 Hz |
| Output | with 5 m cable |
|---|---|
| Connector | Type 2 (IEC 62196-2) |
| Automatic Charging Start | Yes, automatic restart every 3 min after a power outage |
| MID Meter | Optional (certified energy metering) |
| Protocol | OCPP 1.6 |
| Communication | With GSM module |
Key Features
- IP65 Protection
- RFID Card Reader
- Mobile App
- LCD Display
- WiFi
- Scheduled Charging
- OCPP
- Shared Access
- Dynamic Load Balancing
- Automatic Charge Start
- MID Meter (Optional)
- Easy Installation
- Free Management Panel
